DuoModo Echo II DV Thunderbolt 5 Module

Information 2-slot Thunderbolt 5 to PCIe Card Expansion Module Designed for Optimal DV Expansion with Bandwidth-hungry DV I/O Cards Thunderbolt 5 Performance Meets Possibility – Run Two High-bandwidth PCIe Cards at Full 6000 MB/s Simultaneously The latest M-series Macs and Windows PCs feature powerful Thunderbolt 5 and Thunderbolt/USB4 ports, each driven by its own dedicated Thunderbolt bus. Installed in a Sonnet desktop or rackmount enclosure, such as xMac Studio, xMac mini (2024 ), or Echo rackmount systems, Echo II DV T5 Module leverages this architecture to deliver full-performance connectivity to two PCIe 4.0 card slots, each supported by its own Thunderbolt interface for bandwidth-hungry DV I/O cards. Features Designed for High-performance DV I/O PCIe Cards Supports two full-height, full-length PCIe cards, each at full bandwidth Two x16 PCIe 4.0 slots Up to double the bandwidth for double the video channels Supports every single-width Thunderbolt-compatible non-GPU Card See Sonnet’s PCIe Cards Compatibility PDF Thunderbolt 5 Interface Four Thunderbolt 5 ports (two reserved for connection to host computer) Independent Thunderbolt connection to each card slot Thunderbolt 5 interface offers 6000 MB/s of PCIe bandwidth with Thunderbolt 5 computers; 2880 MB/s with Thunderbolt 4 and 3 Built-in 400W power supply with 2x 75W auxiliary power connectors Supports power-hungry, non-GPU cards Powers on and off automatically with connected computer Quiet Fans Dual Noctua fans offer ultra-quiet operation Temperature-controlled, variable-speed Rated at 17dBA Sonnet Product Compatibility Echo III Rackmount Thunderbolt Expansion Systems Echo II DV Rackmount Thunderbolt Expansion Systems xMac Studio Enclosure Systems xMac mini (2024 ) Enclosure Systems DuoModo Desktop or Rackmount Enclosure Systems Sonnet single-module Desktop Enclosure Sonnet dual-module Rackmount Enclosure Mac Compatibility macOS 14 Mac with Thunderbolt 5, Thunderbolt 4, Thunderbolt/USB4, or Thunderbolt 3(1) ports Windows Compatibility Windows 11 computer with Thunderbolt 5, Thunderbolt 4, or USB4(2) ports Linux Compatibility Linux 6.1 or 6.12 computer with Thunderbolt 5, Thunderbolt 4, or USB4 ports Weight and Dimensions (WxDxH) 19.4 lbs (8.80 kg) 19.13 x 16.9 x 3.5 in (48.57 x 42.93 x 8.89 cm) Package Contents Echo II DV T5 Module Region-specific power Two 6-pin PCIe auxiliary power cables (installed) Two 0.8-meter Thunderbolt 5 cables Three ThunderLok-A connector locks Documentation
