Echo III Desktop Thunderbolt 3 Three-Slot PCIe Card Expansion System

Information Connect Three Full-length PCIe Cards to Computers with Thunderbolt 3 or Thunderbolt 4 Ports For creative pros using the latest portable, mini desktop and all-in-one computers in their workflows, onboard processing power alone is not enough to get the job done. While these computers include high-performance Thunderbolt™ 3 ports to support peripherals, what they lack is PCIe expansion slots to install specialty cards that add needed video and audio inputs, transcode data, and connect to high-speed shared storage and networks. Sonnet has a solution—the Echo™ III Desktop—a professional Thunderbolt to PCIe card expansion system that enables you to connect three (up to) full-length (12.28 inches long) PCIe cards at the same time, via a single cable. Features Form Factor • Desktop expansion system External Connectors • Two Thunderbolt 3 ports Internal Connector • 6-pin Mini-Fit Jr (same type as on legacy Mac Pro motherboard; provides up to 75W of power for PCIe cards that require supplemental power) Expansion Slots (Facing Rear, Left to Right) • One x8 mechanical (x8 electrical) PCIe 3.0 • One x16 mechanical (x8 electrical) PCIe 3.0 • One x8 mechanical (x4 electrical) PCIe 3.0 PCIe Cards Supported • Three full-length, full-height, single-width PCIe cards or • One full-length, full-height, double-width PCIe card, plus one single-width card Power Supply • Universal 400W, 115-230V AC, 50-60 Hz Operating Temperature • 0ºC to 35ºC (32ºF to 95ºF) Dimensions (WxDxH) • 3.5 x 16.7 x 9 in. (8.9 x 42.4 x 22.9 cm) Weight • 9.7 lbs (4.40 kg) Compliance • RoHS 3 (Directive 2015/863) • IEC62368-1 and IEC62368-2 Package Contents • Echo III Desktop enclosure • Power cord • 0.7-meter Thunderbolt 3 (40Gbps) cable • ThunderLok 3 Thunderbolt Connector Retainer Clip • Documentation Video
