DuoModo Echo III Module
$ 96.90
Information The DuoModo™ Echo™ III Module connects up to three PCIe cards to computers without card slots. The module supports three full-height, full-length Thunderbolt™-compatible non-GPU PCIe cards; provides 400W of power for the most demanding of PCIe cards, including qualification from Avid for Pro Tools | HDX PCIe cards; features quiet, dual temperature-controlled Noctua fans rated at 17 dbA; and connects through super fast 40Gbps Thunderbolt interface. Three Versatile PCIe Slots 400W of Power Quiet Fans Thunderbolt 3 Interface The choice is yours – mix and match DuoModo™ enclosures with modules to create your own custom Thunderbolt™ expansion system or choose a pre-configured system to help take the guess work out of configuration options. For computers with Thunderbolt 3 or Thunderbolt 4 ports. Features Form Factor: Expansion system module External Connectors: Two Thunderbolt 3 ports Power (C14-type) Internal Connector: 6-pin Mini-Fit Jr (same type as on legacy Mac Pro motherboard; provides up to 75W of power for PCIe cards that require supplemental power) Expansion Slots (Facing Rear, Left to Right): One x8 mechanical (x8 electrical) PCIe 3.0 One x16 mechanical (x8 electrical) PCIe 3.0 One x8 mechanical (x4 electrical) PCIe 3.0 PCIe Cards Supported: One full-length, full-height, double-width PCIe card, plus one single-width card or Three full-length, full-height, single-width PCIe cards Power Supply: Universal 400W, 115-230V AC, 50-60 Hz Operating Temperature: 0ºC to 35ºC (32ºF to 95ºF) Dimensions (WxDxH): 3.3 x 16.6 x 8.5 in. (8.4 x 42.2 x 21.7 cm) Weight: 4.95 lbs (2.25 kg) Compliance: RoHS 3 (Directive 2015/863) IEC62368-1 and IEC62368-2 Package Contents: Echo III Module Power cord 0.7-meter Thunderbolt 3 (40Gbps) cable ThunderLok 3 Thunderbolt Connector Retainer Clip Mounting screws Documentation Mac Compatibility: – Mac (Intel®) with Thunderbolt 3 ports – Mac (M1) with PCIe cards that have M1 compatible drivers – Mac with a Thunderbolt 2 or Thunderbolt port with an Apple Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter plus a Thunderbolt 2 cable (both sold separately) – macOS 10.12.6 – macOS® 10.12.6 – macOS Big Sur compatible Windows Compatibility: – PC with Thunderbolt 3 or Thunderbolt 4 ports – Windows 10 (64-bit Edition Version 2004 or greater, see note) – Important Note: Windows computers require the latest BIOS and Thunderbolt drivers to support this product. Check with your computer manufacturer for update information. Linux Compatibility: – Linux® computer with Thunderbolt 3 or Thunderbolt 4 ports – Linux Kernel 5.0 PCIe Card Compatibility: For a list of compatible PCIe cards, view the PDF of Sonnet’s PCIe Card Thunderbolt Compatibility Chart on Sonnet’s website (updated regularly) Video
